Pipette Calibration and Preventive Maintenance Services

Whether it's cGLP, cGMP, critical research, academia, or special requirements; our experienced service personnel are highly trained in providing exceptional CARE for all pipette models. For over 25 years, we have offered quality-minded service offerings that will surely meet the diverse service needs of our customers.

Our Unity Lab Services team proudly offers two pipette service programs:

Basic Calibration Program: provides a thorough external evaluation of the pipette(s) performance to gravimetrically validate the desired accuracy and precision standards are being achieved.

Preventive Maintenance and Calibration Program: combines a thorough internal and external evaluation of the pipette(s) performance with a high quality repair, preventive maintenance, and calibration program. This ensures gravimetrically that the desired accuracy and precision standards are being achieved.

  Service Offerings
Basic Calibration Service Program1 Preventive Maintenance & Calibration Program Evaluation & Service Program
Measurement Process  2 x 5
3 x 5
2 x 10
3 x 10
2 x 5
3 x 5
2 x 10
3 x 10
Take care of your broken or non-functional pipettes.

We thoroughly evaluate and make recommendations for any further maintenance.

Recommendations and costs are presented to the customer. If the customer agrees to pursue the suggested maintenance, the repairs, PM, and calibration are performed.

If the repair charges are declined the customer only pays the evaluation fee and the pipette(s) are returned promptly.
As Received Data  Optional Optional
Additional Test Volumes & Measurements  Optional:
3 x 5
2 x 10
3 x 10
Optional:
3 x 5
2 x 10
3 x 10
Inspection  10-point inspection2 15-point inspection2
Cleaning  External Cleaning
Functional Leak Check
Internal & External Cleaning
Functional Leak Check
As Returned Data  2 x 5
3 x 5
2 x 10
3 x 10
2 x 5
3 x 5
2 x 10
3 x 10
Preventive Maintenance and Minor Repair
Certificate & Calibration Sticker

1 If a pipette fails the Basic Calibration Program, the customer is contacted with reason(s) for failure and recommended course of action (i.e. a full preventive maintenance service under the PM and Calibration Program). If the PM and Calibration program is authorized by the customer, the pipette(s) will roll over into that service program.

2 Items included in each inspection type

Manual Single and Multichannel Models Electronic Single and Multichannel Models
Basic Calibration Inspection PM & Calibration Inspection Basic Calibration Inspection PM & Calibration Inspection
  1. Pipette Handle (Body)
  2. Plunger Button
  3. Plunger Rod Movement
  4. Volume Lock (as applicable)
  5. Micrometer and Window
  6. Tip Ejection System
  7. Tip Cones
  8. Coupling Nut (as applicable)
  9. Tip(s) Sealing Assurance to the Tip Cone(s)
  10. Liquid Leak Test Confirmation
  1. Pipette Handle (Body)
  2. Plunger Button
  3. Plunger Rod Movement
  4. Volume Lock (as applicable)
  5. Micrometer and Window
  6. Tip Ejection System
  7. Shaft/Tip Cones
  8. Coupling Nut (as applicable)
  9. Piston(s)
  10. Internal Springs (as applicable)
  11. Seal (s)(as applicable)
  12. O-Ring(s)
  13. Lubrication of appropriate components as recommended
  14. Tip(s) Sealing Assurance to the Tip Cone(s)
  15. Liquid Leak Test Confirmation
  1. Pipette Handle (Body)
  2. LCD Clarity and Resolution
  3. Key Pad Functions and Responsiveness
  4. Motor Movement
  5. Tip Ejection System
  6. Tip(s) Cone(s)
  7. Coupling Nut (as applicable)
  8. Tip(s) Sealing Assurance to the Tip Cone(s)
  9. Battery Health and Recharging
  10. Liquid Leak Test Confirmation
  1. Pipette Handle (Body)
  2. LCD Clarity and Resolution
  3. Key Pad Functions and Responsiveness
  4. Motor Movement
  5. Tip Ejection System
  6. Piston(s)
  7. Internal Springs (as applicable)
  8. Seal (s)(as applicable)
  9. O-Ring(s)
  10. Lubrication of appropriate components as recommended
  11. Tip(s) Cone(s)
  12. Coupling Nut Durability (as applicable)
  13. Tip(s) Sealing Assurance to the Tip Cone(s)
  14. Battery Health and Recharging
  15. Liquid Leak Test Confirmation
